模塊混凝士攪拌站系列

MODULAR CONCRETE MIXING PIANT SERIES

項目Item/型號Model  HZS25 HZS35 HZS50 HZS75 HZS100
整機
Whole machine		 理論生產率(m³/h)
Theoreical productivity		 25 35 50 75 100
控制方式
control mode		 微機 Computer
計量方式
Weighing mode		 電子秤 Electrical scale
出料高度
Discharging height		 3.8
整機裝機容量
Whole machinery capacity		 55 85 110 150 180
攪拌機
Mixer		 攪拌機型號
Model of mixer		 JS500 JS750 JS1000 MT1500 MT2000
攪拌機功率
mixing power		 18.5 30 18.5x2 30x2 37x2
入料容積（L）
Charging volume		 800 1250 1500 2250 3000
出料容積（L)
Discharging volume		 500 750 1000 1500 2000
料徑碎石／卵石
Diameter of macadarn/pebble		 40-60 40-60 40-80 40-80 40-80
骨料儲供系統
Aggregate storage system		 配料秤型號
Batcher scale model		 PL800 PL1200 PL1600 DPL2400 DPL3200
配科種類
Types of ingredients		 2－3Piece(種) 3Piece(種) 3Piece(種) 3－4Piece(種) 4Piece(種)
砂石儲料倉容積（m³）
Aggregate storage hopper volume         		 3x2-3 3.4x3 5x3 8x3 15x3
計量范圍及精度
Weighing range & accuracy		 200-1500±2% 200-2000±2% 200-2500±2% 200-3500±2% 200-5000±2%
理論生產能力(t/h)
Theoretical capacity		 80 100 140 190 260
粉料儲供系統
Powder storage       		 粉料存儲能力
Powder storage capacity		 50x1 50x2 100x2 100x2 100x4
螺旋輸送機能力(t/h)
Screw conveyer capacity		 30 35 45 55 80
水泥計量范及精度
Cement weighing range&accuracy		 50-300±1% 50-400±1% 100-600±1% 100-1000±1% 100-1100±1%
水外加劑緒供系統
Water addives storage system		 水計量范圍
Water weighing range		 50-150 50-200 50-350 50-450 50-500
水計量精度
Water weighing accuracy		 ±1%
液態外加劑量范國
Liquid additives weighing range		 5-20 5-20 5-20 5-30 5-60
液態外加劑量精度
Liquid additives weighing accuracy		 ±1%
